ModBus RTU Laser Displacement Sensor FLR-100-RS485

Model:FLR-100-RS485
ModBus RTU Laser Displacement Sensor FLR-100-RS485 Measuring range: 150-1000mm Output mode: with switch quantity and RS485 communication (support ModBus protocol) Linearity accuracy: Standard: ±0.6% F.S; Resolution: 50um at 150mm; 2mm at 1000mm Spot size: Φ3mm at 1000mm Response time: 2ms/16ms/40ms settable
Send InquiryPDF DownLoad
Product Description

ModBus RTU Laser Displacement Sensor FLR-100-RS485 Product Characteristics:

Measuring range: 150-1000mm

Output mode: with switch quantity and RS485 communication (support ModBus protocol)

Linearity accuracy: Standard: ±0.6% F.S;

Resolution: 50um at 150mm; 2mm at 1000mm

Spot size: Φ3mm at 1000mm

Response time: 2ms/16ms/40ms settable

Parameters：

Standard Type
 RS485+1CH
 FLR-10-RS485
 FLR-50-RS485
 FLR-100-RS485

4-20mA+1CH
 FLR-10-AA
 FLR-50-AA
 FLR-100-AA

High Precision Type

RS485+1CH
 FLR-10-RS485-M
 FLR-50-RS485-M
 FLR-100-RS485-M

4-20mA+1CH
 FLR-10-AA-M
 FLR-50-AA-M
 FLR-100-AA-M
Spot Size
 1*3mm@100mm
 ф2.5mm@500mm
 ф3mm@1000mm
Measuring Range
 30-100mm
 80-500mm
 150-1000mm
F.S
 70mm
 420mm
 850mm
Standard Type:

Linear Accuracy

RS485:+0.3%FS.4-20mA:+0.4%FS
 RS485:+0.3%FS.4-20mA:±0.4%FS
 士0.6%FS
High Precision Type:

Linear Precision

0.1%F.S.
 80-250mm:+0.15%FS250-500mm:士0.3%FS
 150-450mm:士0.3%FS450-1000mm:±0.6%FS
Repeatability
 10um@30mm
 30um@80mm
 100um@150mm
30um@50mm
 250um@250mm
 520um@500mm
100um@100mm
 1000um@500mm
 4000um@1000mm
Resolution Ratio
 5um@30mm
 15um@80mm
 50um@150mm
50um@100mm
 500um@500mm
 2000um@1000mm
Light Source
 Red laser (650nm); Laser level: Class ll
Supply Voltage
 RS485:10~30VDC/4-20mA:12~24VDC
Pressure Drop
 <2.5V
Power Consumption
 <700mW
LOAD
 <200mA
Protection Circuit
 polarity protection,surge protection, overload protection
