laser displacement range sensor pnp A high-precision CMOS image sensor used in a displacement sensor is usedand our unique algorithm that has been used in displacement sensorsUnprecedented accuracy(1/100mm) of a distance-setting reflective sensor

laser displacement range sensor analog 4~20 mA 0-5 V Part number：FSD22-100N-UI Measurement center distance：100mm Measurement range：±35mm Linearity:±0.3%F.S. Beam diameter ：ø120μm Repeatability：100μm Control output：NPN Supply voltage：12 to 24V DC ±10% Analog voltage output：Output range: 0 to +5V (at alarm: +5.2V) Analog current output：Output range: 4 to 20mA (at alarm: 0mA) Response time：Switchable between 1.5ms / 5ms / 10ms Protection：IP67 Ambient temperature：-10 to +45°C (No dew condensation or icing allowed), Storage:-20 to +60°C

Laser displacement range sensor Small size, small light point; High detection accuracy, ultra-high cost-effective; at the same time with switching and analog dual output; a variety of detection mode function can be applied to more applications Top design has a large output indicator, more intuitive: clear and bright white digital tube display, more high-end: membrane key, easy to set up the operation is convenient; aluminum alloy shell, sturdy and durable.​

Laser Distance measure Sensor Small size, small spot; High detection accuracy and high price-performance ratio; Dual switching and analog outputs at the same time. Multiple detection modes for more applications. Large output indicator on the top for better visualization; and High-end display with bright white digital tube; Membrane keypad for easy operation and setup. Membrane buttons for easy operation and setup. Aluminum housing for ruggedness and durability.​

high precision laser displacement range sensor Designed for industrial applications demanding sub-micron accuracy, our high precision laser displacement range sensor delivers unparalleled stability with 10μm resolution for ultra-fine measurement tasks. Leveraging advanced laser triangulation technology, this sensor ensures reliable detection of minute displacements, surface profiles, and dimensional variations in real time.

CMOS Optical Laser Distance Sensor Small size and small spot; High detection accuracy and high price-performance ratio; Dual output of switching and analog at the same time. Multiple detection modes for more applications; and Large output indicator on the top for better visualization; and High-end display with bright white digital tube; Membrane keypad for easy operation and setup. Membrane buttons for easy operation and setup. Aluminum housing for ruggedness and durability.

​High Frequency Industrial Distance Measuring Sensor FLR-10000N-UIR IP67 OLED Digital CMOS High Frequency Industrial Distance Measuring Laser Displacement Sensor

High accuracy 0.01mm Laser displacement sensor offers 60-110mm measurement range with ±0.1% F.S. linearity and 60μm repeatability. Features dual outputs (switching signals + RS485 ModBus), Φ0.5mm spot for tiny object detection, IP67 protection, and NPN/PNP adaptability. Easy setup via digital display, supports 32-sensor networks. Ideal for automated QC in electronics and automotive, ensuring non-contact, wear-free precision.

Measuring range: 60-110mm Output mode: with switch quantity, current 4-20mA Linearity accuracy: standard type: ± 0.4% F.S. (60-110mm); high precision type: ± 0.1% F.S. (360-110mm) Repeatability: 60um Resolution: 30um Spot size: Φ0.5mm at 85mm flatness range 85mm Laser displacement sensor Response time：2ms/16ms/40ms可以设置 Ambient light resistance: incandescent light ≥ 3,000lux Operation panel: OLED digital display Temperature drift: ±0.02%F.S./°C
