FUWEI FW-2104 Photoelectric Label Sensor For Non-Transparent Labels

Model:FW-2104
The FW-2104 is a photoelectric label sensor designed to detect non-transparent labels such as paper, PVC, and PU. With a fast 50μs response time, NPN/PNP output, and durable metal housing, it offers high performance and excellent cost-efficiency, ideal for high-speed labeling systems.
Send InquiryPDF DownLoad
Product Description

FW-2104 Photoelectric Label Sensor

Model number:FW-2104N

Light source:940 um infrared modulated light

Qutput type:NPN NO/NPN NC

Working mode:NO/NC selectable

Supply voltage:12-24VDC

Slot width:2mm

load current:100mA

Working current:1.1mA

Response time:0.1ms

Switch frequency:10KHZ

Response time:50us

Applicable to non transparent labels

Product display:


Application:


Dimensions:

Wiring diagram:

Specification:

Model number
 FW-2104N
Light source
 940um infrared modulated light
Qutput type
 NPN NO/NPN NC
Working mode
 NO/NC selectable
Supply voltage
 12-24VDC
Slot width
 2mm
Slot depth
 39.5mm
Sensitivity setting
 knob adjustment
load current
 100mA
Working current
 1.1mA
Response time
 0.1ms
Switch frequency
 10KHZ
Response time
 50us
Feature
 Cost-effective, fast response time
Detectable label
 Non-transparent paper-based labels
Operating temperature
 -20~55°℃ ,no freezing
Ingress Protection rating
 IP66
Size
 59*9.8*34.7mm

Hot Tags: photoelectric label sensor, opaque label detection, paper label sensor, PVC label detector, PU label sensor, high-speed label eye, NPN PNP output sensor
